1064nm Laser
Precilasers' 1064nm laser, featuring narrow linewidth and low noise, can be applied in fields such as neutral atom trapping and precision measurement.
Features
- Narrow Linewidth
- Tunable
- Linear Polarization
- Continuous-Wave Laser
Application
- Neutral Atom Trapping
- Precision Measurement
Main parameters
|
Specification |
||||||||
|
Wavelength Range |
1064nm |
|||||||
|
Output Power |
5W |
10W |
30W |
50W |
100W |
130W |
200W |
|
|
Tuning Range（Temperature） |
＞0.7nm |
|||||||
|
Output Mode |
Spatially Collimated Output（1） |
Fiber-Coupled Output |
||||||
|
Linewidth(2)(100s Integration Time) |
＜5kHz(3) |
＜10kHz |
||||||
|
Polarization Extinction Ratio |
＞20dB |
|||||||
|
Power Stability |
＜0.75%@3hours, RMS |
|||||||
|
Beam Quality |
M2＜1.1 |
|||||||
|
Intensity Noise（10Hz-10MHz integration） |
＜0.05% |
|||||||
|
PZT Tuning Range |
＞3GHz |
|||||||
|
PZT Tuning Bandwidth |
＞5kHz |
|||||||
|
Cooling |
Air Cooling |
Water Cooling |
||||||
(1)Output Power ≤ 30W, Optional
(2)Measured by Fiber Delay Self-Heterodyne Beat Note Method
(3)Narrow Linewidth Option: Linewidth < 5kHz
Options |
|
|
AOM Option |
An AOM and VCO driver are integrated between the seed laser and the amplifier, achieving a tuning bandwidth of 500kHz and a tuning range of > ±5MHz. |
|
EOM-RF Option |
An EOM is integrated between the seed laser and the amplifier to realize sideband modulation. |
Other Specifications |
|
|
Power Supply |
100V-220V, AC, 50Hz |
Higher power, more wavelengths, customizable solutions
