355nm Solid-state picosecond laser
The solid-state laser-based solution achieves high repetition rate, high power 355nm laser output, which is suitable for applications such as precision detection.
Features
- Narrow Pulse Width
- High Power
- Excellent Beam Quality
- High Power Stability
Application
- Atomic and Molecular Photophysics
- Quantum Computing
- Semiconductor Inspection
Main parameters
|
Specification |
||||
|
Partnumber |
PL-PS-355-xx(1) |
|||
|
Center Wavelength |
355nm(2) |
|||
|
Operation Mode |
pulse |
|||
|
Average Power |
>1W |
>5W |
>8W |
|
|
Repetition Rate |
70MHz-100MHz(3) |
|||
|
Repetition Rate Lock Option |
＜1mHz@24h |
|||
|
Pulse Width(4) |
<50ps @1064nm |
<20ps @1064nm |
||
|
Spectral Width(4) |
<60pm @1064nm |
<100pm @1064nm |
||
|
Beam Waist Diameter |
1.3-1.7mm |
|||
|
Beam Divergence |
<0.5mrad |
|||
|
Pointing Stability |
<20urad/K |
|||
|
Power Stability |
<0.75% @3hrs, RMS |
|||
|
Beam Quality |
TEM00，M²<1.2 |
|||
|
Cooling |
Water Cooling |
|||
(1) XX laser power, in W, for example, output power 8W: PL-PS-355-8.
(2) Other central wavelengths can be customized
(3)(4) Repetition rate and pulse width can be customized
|
Other Parameters |
|
|
Temperature |
15-35℃(No condensation conditions） |
|
Power Supply |
100V-240V AC, 50/60Hz |
Higher power, more wavelengths, customizable solutions
