1530-1590nm Femtosecond laser
The Erbium-doped femtosecond seed laser is engineered for robustness and stability in demanding environments. Key Specifications Core Technology: Utilizes Nonlinear Amplifying Loop Mirror (NALM) technology. Stability: Achieves long-term, high-stability pulsed output. Environmental Tolerance: Suitable for operation in both high and low-temperature environments.
Features
- Broad Spectrum
- High Power
- Linear Polarization
- Customizable Wavelength
- High Power Stability
Application
- Atomic and Molecular Photophysics
- Precision Measurement
- Ultrafast Imaging
- Precision Machining
Main parameters
|
Specification |
||
|
Customizable Central Wavelength |
1530-1590 nm |
|
|
Pulse Width |
Compressible to <100 fs |
|
|
Pulse Energy |
0.5-3 nJ |
|
|
Average Power |
6-200 mW |
|
|
Maximum Peak Power |
>20 kW |
|
|
Spectral Width |
>15 nm |
|
|
Repetition Rate |
50-140 MHz selectable |
|
|
Operating Mode |
Pulsed |
|
|
Operating Environment & Power Supply |
||
|
Temperature(No condensation conditions) |
15-35 ℃ |
|
|
Power Supply |
12V, DC |
100V-240V, AC, 50/60Hz |
|
Communication |
RS422 |
|
|
Chassis Dimensions |
225mm×120mm×40mm(<10mW) |
483mm×367.5mm×50mm(>10mW) |
Higher power, more wavelengths, customizable solutions
